510 Speed Stream_ Hight-Definition Streaming and Telemetry (HDT_PRO)

High Definition Streaming Video and Telemetry System (HDT PRO) is a lightweight, low latency 4K video and telemetry streaming system for any mobile application.

Ultra-low latency

HDT PRO broadcasts low latency high-quality 4K video at low bit rates.
Ultra-low latencies are suitable for remote broadcast studios and real-time monitoring, feedback, and control.
Utilizes the latest 4G/5G technology to stream 4K video and full-duplex RS232 telemetry.

Light Weight & Durable

HDT PRO weighs in at 0.825 lb. It withstands harsh environments: high temperature, vibration, water, and dust.
The small housing is durable synthetic polyamide (nylon). It features two unique cable tie mounts making it fast and easy to install in any mobile
or wearable application.

Interfaces

  • HDMI Input: Connect GoPro, V-Box, or any HDMI camera.
  • Full duplex RS232 port. Connect any RS232 telemetry stream or GPS
  • Power input: 7-36 VDC.
  • SMA Antenna ports: MIMO dual diversity 4/5G antenna.
  • Dual SIM card slot provides automatic failover and carrier diversity.
  • Configurable input and output. Monitor digital and analog inputs or digital output control. (Optional)
  • Micro SD Card slot, record video. (Optional)
  • External Analog Audio input. (Optional)
  • WIFI connectivity (Optional)

Video Input

  • HDMI Input

Video Input Resolution

  • 3840x2160p 30/29.97/25/24/23.98 Hz
  • 1920x1080p 60/59.94/50/30/29.97/25/24/23.98 Hz
  • 1920x1080i 60/59.94/50 Hz
  • 1280x720p 60/59.94/50/30/29.97/25 Hz

Video Compression

  • H.265
  • H.264
  • Bitrate 40Mbps
  • Configurable:
    • GOP IBBP
    • CBR/VBR
    • Frame rate
    • Resolution

Video IP Network Interface Protocol

  • SRT, RTSP, RTMP, RTP, HLS, FLV, ONIF, TS

Video Input Audio

  • Bitrate 384Kb/s @ 24bit
  • Encoding G.711A, MP3, AAC, AAC+, AC3, MP3, MP2

Cellular Download Speed

  • Max 600 Mbps

Cellular Upload Speed

  • Max 150 Mbps

Cellular Carrier

  • AT&T_FirstNet
  • Verizon
  • Sprint
  • US Cellular
  • Tellus
  • *Dual SIM Slot

Serial

  • TCP, UDP, Modbus
  • Max Baud 115200
  • Full Duplex. RX/TX

Power

  • Voltage Input 7 to 36 VDC @ 1.2A Max

Temperature

  • -40 ºF to 167 ºF ( -40 ºC to 75 ºC)

Construction

  • Synthetic polyamide (nylon)

Weight

  • 0.825 lb

Made in America
