MoTeC PDM 32

MoTeC’s new 32 output Power Distribution Module (PDM32) is designed to provide electronically switched power to the various electrical systems in the vehicle such as motors, lights and solenoids, and electronic devices such as ECUs and data acquisition systems. The module replaces conventional relays, fuses and circuit breakers, simplifying wiring and reducing weight, while increasing reliability. Features:

  • Each output is over-current, short circuit and thermal overload protected
  • Outputs programmable in 1 A steps
  • Outputs controllable via a combination of switch inputs, CAN messages and logic functions
  • Switch inputs ranging from 0 to 51 V, resolution 0.2 V
  • Performing up to 200 logic operations using operators like Flash, Pulse, Set/Reset, Hysteresis, Toggle, And, Or, Less than, Greater than, Not equal to, Equal to, True, False etc.
  • Performing functions such as flashing indicator lights and controlling thermofan and fuel pump
  • Using logic functions to selectively turn off systems during low battery voltage or engine starting, reducing drain on the battery
  • Providing full diagnostic information, including output currents and voltages, input voltages, and error status
  • Transmitting diagnostic information via CAN to a display or data logging device or monitoring directly on a PC
Manufacturer MoTeC
Included In Box MoTeC PDM16
Manufacturers Part No 14102
Dimensions (mm) 130 x 60 x 28 mm
Weight (g) 300
Chassis Material Aluminium
Environmental Sealing None
Power Requirement NA
Max Current Draw No
Battery No
Connector Grade Pro
Connectors 1 x 26 pin Autosport connector 1 x 1 pin Autosport connector 1 x 8 pin Autosport connector
8 A Outputs 8
20 A Outputs 8
Total Output Current 100A
Switch Inputs 12
