RaceGrade TC8 Thermocouple to CAN

The RaceGrade TC8 is a CAN based device that reads in up to 8 thermocouple temperature sensors, typically used for EGT, exhaust gas temperature measurement.


  • Small, lightweight & compact package
  • Easy to adapt and wire into any vehicle, just 4 wires; power, ground, CAN high and CAN low.
  • Built in amplifiers for up to 8 channels
  • Splash protection, but not waterproof

Input Temp Range: 0 to 1000*C
Thermocouple Style: K-type only
Operating Voltage Range: 9 to 24vDC
Operating Current Draw: < 0.1 Amps
Operating Temp Range: -40*C to 120*C
Dimensions: 3.5"x2.26"x1.0"
Weight: 173 grams
Mating Connector: ASL606-05SN
